Pull Type Tubular Solenoid

The pull-type tubular solenoid series S-20-100X features 18 different standard solenoids based on voltage, duty cycle, force and stroke requirements. Force ranges from 61 N (220 Oz) at near zero (hold) and 10% duty cycle to 1.1 N (4 Oz) at 25.4mm (1.0 inch) and continuous (100%) duty cycle.

This series typically utilizes class F (155 deg C) coil windings of 23 to 40 AWG and lead wires with class A (100 deg C) PVC insulation to protect the solenoid during long duty cycles. Higher temperature insulations are available upon request.

These solenoids are ideal for valve controls, door controls, cabinet locks, disconnects, transmission shifting, fire suppression systems, medical dispensing, mixing, and sorting equipment.

These clean, highly efficient, low cost, precise tubular solenoids utilize noncaptive plungers (actuators) with a clevis end for load attachment. A low-friction brass guide and PTFE coating on the plunger assures long life.

duty cycle

1 (100%)

1/2 (50%)

1/4 (25%)

1/10 (10%)

maximum "ON” time, (Sec.)

infinite (∞ )

400

35

10

watts

10

20

40

100

approximate ampere turns

1110

1590

2220

3510

coil wire size (AWG)

coil resistance (Ω)

volts DC

volts DC

volts DC

volts DC

23

1.52

3.9

5.5

7.8

12.3

24

2.95

5.4

7.7

10.9

17.2

25

4.01

6.3

9.0

12.7

20.0

26

7.10

8.4

11.9

16.9

26.6

27

9.92

10.0

14.1

19.9

31.5

28

17.1

13.1

18.5

26.2

41.4

29

27.5

16.6

23.5

33.2

52.4

30

46.2

21.5

30.4

43.0

68.0

31

72.0

26.8

37.9

53.7

84.9

32

110

33.2

46.9

66.3

105

33

175

41.8

59.2

83.7

132

34

270

52.0

73.5

104

164

35

450

67.1

94.9

134

212

36

665

81.5

115

163

258

37

1040

102

144

204

323

38

1550

125

176

249

394

39

2750

166

235

332

524

40

4350

209

295

417

660
