Tubular Low Profile Push/Pull Solenoid

duty cycle

1 (100%)

1/2 (50%)

1/4 (25%)

1/10 (10%)

maximum "ON” time, (Sec.)

infinite (∞ )

230

90

30

watts

20

40

80

200

approximate ampere turns

1200

1700

2400

3800

coil wire size (AWG)

coil resistance (Ω)

volts DC

volts DC

volts DC

volts DC

19

1.4

5.2

7.3

10.3

16.3

20

1.8

5.8

8.2

11.5

18.2

21

3.0

7.7

10.9

15.3

24.3

22

4.5

9.6

13.6

19.2

30.5

23

7.8

12.1

17.2

24.2

38.3

24

12.0

15.5

21.9

31.0

49.0

25

18.5

19.1

27.1

38.3

60.6

26

32.5

25.1

35.5

50.2

79.4

27

48.4

31.4

44.5

62.8

99.4

28

75.2

39.6

56.1

79.2

125

29

127

50.9

72.1

102

161

30

201

63.4

89.9

127

201

31

313

78.3

111

157

248

32

469

97.6

138

195

309

33

770

124

176

249

393

34

1330

161

228

321

509

35

2257

207

293

413

654

S-16-264 Low-Profile Solenoid Features and Applications

Key Features

Pull Type low-profile construction; 2.625 in (66.7 mm) diameter; 1.56 in (39.6 mm) body length; 34.7 oz (984 g) total weight; four duty-cycle ratings; and multiple coil windings for a range of DC operating voltages.

Typical Applications

The S-16-264 may be considered for latches, releases, valves, locks, indexing mechanisms and other short-stroke pull-actuation functions in industrial equipment. Verify force, stroke, duty cycle, heat sinking and environmental requirements for the final design.

For mechanical dimensions and performance information, see additional S-16-264 data or download the PDF datasheet, or use the 3D STEP model. For application assistance, contact Magnetic Sensor Systems.
